Error Code Mesin Fotocopy Canon IR 4570/3045

Kode Eror yang umum terjadi di Mesin Fotocopy Canon IR 2870/3570/4570/3030/3035/3045/3245

CODE  DESCRIPTION CODE  DESCRIPTION
E000 fixing overheating E001  fixing assembly overheating
E002 fixing assembly low temperature E003 post-standby fixing low temperature
E007 fixing film rotation error E010 main motor rotation error
E014 fixing motor rotation error E019 waste toner case full, waste toner case full sensor error
E020 toner clogging between sub hopper and developing assembly E024 developing assembly connector disconnection
E025 hopper motor, bottle motor error E032 NE controller counter error
E064 power supply voltage error (high-voltage) E100 BD interval error
E110 scanner motor error E191 communication error for high voltage power supply
E202 CIS home position detection error E225 CIS light intensity error
E227 reader unit power supply error E248  backup memory error
E261  zero-cross signal error E315  image data error
E400 feeder communication error E490 wrong DF type
E500  finisher communication error E503  finisher internal communication error
E505  finisher backup memory error E514  stack delivery/trailing edge assist motor error
E519  gear change motor error E520  off-set motor error
E530  rear alignment error E531  stapling error
E532  stapler shift error E535  swing error
E537  front alignment error E540  stack tray ascent error/upper tray ascent error
E542  lower tray ascent error E577  paddle error
E584  shutter error E590  punching error
E591  puncher dust sensor error E592  punch horizontal registration sensor error
E593  punch shift error E5F0  saddle paper positioning error
E5F1  saddle paper folding error E5F2  saddle guide error
E5F3  saddle alignment error E5F4  saddle rear stapling error
E5F5  saddle front stapling error E5F6  saddle butting error
E5F8  saddle connector error E5F9  saddle switch error
E602  hard disk error E604  image memory error/shortage
E609  hard disk error E610  hard disk coding key fault
E674  fax board communication error E710  IPC initialization error
E711  IPC communication error E713  communication error for finisher
E716  communication error for pedestal/ communication error for 3-way unitA1 E717  communication error for NE controller
E719  coin vendor error E730  PDL software error
E732  scanner communication error E733  printer communication error
E740  Ether board error E743  DDI communication error
E744  language file/boot ROM error E745  TokenRing board error
E746  accessories board wrong model error E748  controller board and SDRAM size mismatch
E805  fan error



Comments (2)

Andi Budiman
Reply

Mesin IR 4570 saya error kodenya E000225-0001, artinya apa ya?

Andi Budiman
Reply

Apakah sama dengan yang di tabel yaitu E225 (CIS light intensity error), kalau iya itu maksudnya apa, dan bagaimana cara memperbaikinya? Terimakasih.
